The Hayward 1 1/2″ Multiport Valve (Model SP0710X62) is a six-position “Vari-Flo” control valve made for side-mount sand filters. It allows you to switch between modes like Filter, Backwash, Rinse, Waste, Recirculate, and Closed. The valve body is made from reinforced thermoplastic, making it durable and resistant to pool chemicals.
Key Features
-
Port Size: 1.5″ FIP or FPT connections.
-
Mounting: Side-mount design, suited for filters like the Hayward Pro-Series S210S, S244S, S310S.
-
Valve Functions (6): Filter, Backwash, Rinse, Waste, Recirculate, Closed.
-
Material: Reinforced thermoplastic for long life and chemical resistance.
-
Sight Glass: Built-in, to visually check water clarity during backwash.
-
Low Pressure Drop: Engineered for high flow with minimal pressure loss (Vari-Flo design).
-
Color: Black.
Benefits
-
Versatile: One valve handles all common filter modes, making maintenance simpler.
-
Efficient Filtration: High flow with low pressure drop helps your system run better.
-
Durable & Reliable: Strong materials hold up under chemical exposure.
-
Easy to Maintain: The sight glass helps you know exactly when the backwash is complete.
-
Compatible: Works with many Hayward side-mount sand filters.
| 5 star | 0% | |
| 4 star | 0% | |
| 3 star | 0% | |
| 2 star | 0% | |
| 1 star | 0% |
| Specification | Detail |
|---|---|
| Model / Part Number | SP0710X62 |
| Valve Type | Vari-Flo Multiport, 1.5″ |
| Mounting | Side Mount |
| Connections | 1.5″ FIP / FPT |
| Positions | 6 (Filter, Backwash, Rinse, Waste, Recirculate, Closed) |
| Material | Reinforced Thermoplastic |
| Approx. Weight | ~6 lbs (according to Vita Pool Supply) |
